Newly CNC Straight And Reverse Twisted Hexagonal Wire Mesh Chicken Fence Weaving Machine
Product Description
Hexagonal wire mesh making machine is our main product, the main type is 3/8,1/2, 5/8,.3/4, 1,1.2,1.5,2 inch and so on.The machine can produce the mesh wire and the max width are 1.2m and 2.3m. The machine with 2.3m mesh width can produce two 1m mesh at the same time. The wire diameter is usually range from 0.38mm to 1.3mm. It depend on the mesh size.
Product Advantage
1.Accessories: one set spool winding machine and one set spring winding machine
2.Smooth running, low noise, automatic stop system
3.Used clutch arrester, easily operate
4.Concentrate lubricating system, simply operate also
5.Spring winding machine: 2.05*0.7*1.5m 100kg 0.75kw
6.Spool winding machine: 0.85*0.7*1m 50kg 0.75kw
Technical Parameter
| Mode type | The machine width ( m) | The mesh size (mm) | w ire diameter(mm) | Speed(m/h) | Dimension(m) | Power(kw) | Weight (T) |
| 1/2” | 2.0-4.5 | 15*22 | 0.35-0.7 | 65-220 | (4.2-6.2)*1.7*1.6 | 13.9 | 3.8-5.0 |
| 3/4” | 20*35 | 0.35-0.8 |
| 1” | 25*38 | 0.35-1.2 |
| 1.2” | 30*40 | 0.35-1.2 |
| 1.5” | 40*53 | 0.5-2.0 |
| 2” | 50*85 | 0.6-2.2 |
| 3” | 80*100 | 0.6-2.4 |
| 4” | 100*140 | 0.8-3.0 |
Product Image
Finished Products
Certification
Packing&Delivery
FAQ
Q: Can I know the machine width you can do?
A: For this machine, the normal width is 2M, 2.6M and 3.3M.
We can also special customized the 4M, 4.3M and 4.7M width machine.
Q: What is the production of the machine?
A: For the mesh opening 1/2’’, the production is about 60m/h; for 1’’ opening, the production is 100m/h.
Q: What is the payment terms?
A: 30%T/T in advance, 70% T/T before shipping, or 100% irrevocable L/C at sight, or cash etc.
Q: What’s your packing way of the machine?
A: Main machine with plastic package and would be stabled by steel wire. The spare parts in the wood box ,auxiliary equipment in the container.
Q: How many machines can be loaded in one container?
A: One 40 feet container can load 2 sets machine.
Q: How many days of delivery time of the machine?
A: 3P,380V, 50HZ, 20-25 days after received your advanced payment,
Other voltages, 35 days after received your advanced payment
Q: How to install the machine?
A: Our best engineers can go to your factory for installing& training. Or you can install the machine by yourself, we will send video how to install the machine.
